The Canadian well, also known as an earth-to-air heat exchanger, is based on a simple yet ingenious principle: using the stable temperature of the ground to temper the air entering a building. At about two meters below the surface, the soil maintains a nearly constant temperature of 10 to 13 °C throughout the year. This natural thermal difference allows the system to preheat incoming air in winter and cool it in summer simply by circulating it through buried pipes [1][2].

How It Works: A Subtle but Effective Exchange

A Canadian well operates through thermal exchange between the ground and incoming air. Its efficiency depends on several key parameters:

Burial depth (1.5 - 3 m): deeper installations benefit from more stable soil temperatures.
Pipe length and diameter, which define the available heat exchange surface.
Soil composition, since moist or clay soils conduct heat better than dry soils.
Airflow rate, which must balance efficient heat transfer and limited condensation.

In France, IZUBA Énergies, commissioned by ADEME, validated this principle through a field study on a house in Presles (Val-d’Oise). Measurements showed a temperature difference of less than 2 °C between simulated and measured outlet air 98 % of the time, and up to 40 % savings on air-heating needs in winter [4]. The soil therefore acts as a natural thermal buffer, storing and releasing heat seasonally without the need for mechanical refrigeration.

A major large-scale example is the Research Support Facility (RSF) of the National Renewable Energy Laboratory (NREL) in Colorado (USA), a 22,000 m² LEED Platinum office building. It uses 42 buried earth-to-air tubes to precondition 100% of outdoor air before ventilation. This passive strategy contributes to the building achieving a 51–56% lower total energy use than a comparable office building in the same climate, supporting its near net-zero-energy performance [3][12].

The soil thus acts as a natural thermal buffer, storing heat or coolness depending on the season and limiting the use of energy-intensive systems. This principle is now applied in several commercially available solutions. For example, some manufacturers offer air-to-water exchange modules specifically designed for ground-air heat exchangers, such as the Helios “SEWT-W-2565” module, an air-water exchanger intended for the thermal pre-treatment of fresh air and equipped with a condensate recovery system [6]. For hydraulic installations, the French company MyDATEC also markets glycol-water Canadian well systems, in which a water-glycol mixture improves heat transfer and simplifies maintenance particularly in collective and public buildings [7].

Types of Systems

Depending on building type and climate, several configurations of Canadian wells can be implemented.

Air-Based System

This is the most common design. Outdoor air circulates directly through underground pipes before entering the building. The Fiabitat technical guide [5] highlights several design priorities:

maintaining a steady downward slope to drain condensate
ensuring effective drainage
positioning the air intake away from pollution sources (roads, parking lots)
choosing durable materials such as HDPE (high-density polyethylene) pipes, which are corrosion-resistant and provide good thermal inertia.

Fluid-Based System

Another option uses a glycol-water mixture circulating in a buried network. Heat is transferred to the air through an exchanger, avoiding direct contact between the air and soil. This setup limits humidity and microbial growth, making it suitable for public or multi-unit buildings [5].

Coupling with a Heat Pump

The Quevillon (2017) study [8] explored how an earth-to-air exchanger can be connected to an air-source heat pump. The pre-heated air entering the outdoor unit helps:

increase the COP
reduce defrost cycles in cold weather
stabilize annual operation.

Provençal Well

When mainly used for summer cooling, the system is referred to as a Provençal well. According to Passivact.fr, such systems can reach up to 90 % efficiency in passive houses, where cooling needs are already minimal [9].

Advantages and Innovations: Between Sobriety and Comfort

Energy Performance and Measured Savings

The ADEME–IZUBA study [4] showed that a Canadian well can reduce energy consumption for air-heating by roughly 40 %. The Fiabitat guide [5] adds that, for a single-family home, savings can reach 1,700 kWh per year, with a COP around 12 and a power draw of only 135 kWh per year (mainly for ventilation fans). These numbers illustrate the well’s value in low-energy building design.

These figures highlight the relevance of the system for low-energy buildings. A concrete example illustrates this approach: the “Canadian High-Performance Hydraulic Well” developed by Brink Climate Systems. Designed around an insulated polypropylene heat exchanger and supplied by a glycol-water circuit, it directly exploits the stable ground temperature (around 12 °C) to preheat or cool incoming air exactly according to the principle studied by ADEME and IZUBA. This type of hydraulic Canadian well, identified as one of the most efficient configurations in Fiabitat’s analyses, makes it possible in practice to reproduce the reported savings, including the reduction of fresh-air heating demand and the very low associated electrical consumption [11].

A large-scale application illustrates how these principles extend beyond residential buildings: the Cambridge Public Library (USA) integrates a system of earth-to-air tubes to precondition all incoming fresh air before mechanical ventilation. The air circulates through buried concrete ducts where it exchanges heat with the ground, stabilizing its temperature throughout the year. This reduces winter heating demand by supplying air closer to indoor setpoints and helps limit overheating in summer without active cooling. As a public building with high fresh-air requirements, the library demonstrates how ground-air exchangers can meaningfully improve ventilation energy performance at the scale of multi-storey institutional facilities [12].

Indoor Comfort and Air Quality

By stabilizing air temperature, a Canadian well helps reduce thermal fluctuations and enhances perceived comfort. At about two meters underground, soil temperature remains near 12 °C [2]. This keeps supply air milder in winter and cooler in summer. When combined with a dual-flow ventilation system, it also contributes to higher indoor air quality while minimizing thermal losses.

Bioclimatic Integration

The Eole-FR guide reports that ventilation accounts for 20–30 % of a building’s heat losses [1]. By pre-warming or pre-cooling outdoor air, a Canadian well can reduce the size and capacity of mechanical heating and cooling systems, lowering both initial and operational costs. It thus fits naturally into a bioclimatic building approach, where passive principles work alongside modern technology.

Climate Resilience and Durability

In a warming climate, the Canadian well serves as a passive buffer against extreme temperatures. BatirBio.org estimates that a well-designed system can reduce up to 70 % of the energy used for cooling passive buildings [9]. With a service life of 30–50 years [5] and no refrigerants or compressors, it remains one of the most sustainable and low-impact HVAC solutions available.

Conclusion

The Canadian well stands out as both an ancient and forward-looking technology. By harnessing the earth’s natural stability, it reduces energy demand, improves thermal comfort, and lightens the load on active HVAC systems.

The ADEME and IZUBA studies, along with large-scale projects such as the NREL RSF and the Cambridge Public Library, demonstrate its effectiveness and relevance in an energy transition grounded in efficiency and sobriety.
